Features
TRUE CONVECTION COOKING
True convection cooks food faster by using a rear fan and third heating element to circulate hot air over, under, and around food. (Compared to traditional thermal-bake cycle on the same model.)
SPEEDHEAT™ BURNER
Generate the high heat needed for rapid boiling, searing and frying with multiple Power™ burners that offer up to 15,000 BTUs.
CENTER OVAL BURNER
The oval shape of this fifth burner fits large griddles and other longer cookware so they heat evenly on the range top.
Additional Features
FROZEN BAKE™ TECHNOLOGY
Frozen Bake™ technology cooks frozen foods faster by eliminating the need to preheat the oven for your favorite foods such as frozen pizza, lasagna, chicken nuggets, fries and pies.
EZ-2-LIFT™ HINGED CAST-IRON GRATES
Get quick access to spills on the cooktop with our industry-first EZ-2-Lift™ hinged cast-iron grates. The hinged design allows you to wipe up under them without removing them entirely. For a more thorough clean, the grates are also dishwasher-safe.
CONVECTION CONVERSION
Take the guesswork out of convection cooking with Convection Conversion. It takes the normal cooking time and temperature and turns it into the faster convection equivalent for you.
TEMPERATURE SENSOR
A built-in sensor monitors oven temperature and adjusts the cooking elements to help food bake evenly.
RAPID PREHEAT
Rapid Preheat uses the bake and broil elements to heat the oven quickly and efficiently.
STEAMCLEAN OPTION
Clean up after everyday light spills using heat and only 1-1/4 cups of water-no harsh chemicals or cleaners needed. Used periodically to clean light spills on the bottom of the oven, it keeps the oven clean and reduces the need for frequent self-clean cycles.
Specifications
General
Fuel Type
Natural Gas
Installation Type
Freestanding
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Appliance Care
SteamClean Option
Cooktop
Burners/Elements
5
Burners/Elements Output
• Left Front Element-Burner Power: 16,000 BTU
• Left Rear Element-Burner Power: 5,000 BTU
• Center Rear Element-Burner Power: 7,350 BTU
• Right Front Element-Burner Power: 10,000 BTU
• Right Rear Element-Burner Power: 5,000 BTU
• Left Rear Element-Burner Power: 5,000 BTU
• Center Rear Element-Burner Power: 7,350 BTU
• Right Front Element-Burner Power: 10,000 BTU
• Right Rear Element-Burner Power: 5,000 BTU
Burners
Sealed
Oven
Capacity (cu. ft.)
• Total: 6.0 cu. ft.
• Upper: 2.1 cu. ft.
• Lower: 3.9 cu. ft.
• Upper: 2.1 cu. ft.
• Lower: 3.9 cu. ft.
Number of Ovens
Double
Features
Technologies
• Frozen Bake™ Technology
• EZ-2-Lift™ Hinged Cast-Iron Grates
• SpeedHeat™ Burner
• True Convection Cooking
• EZ-2-Lift™ Hinged Cast-Iron Grates
• SpeedHeat™ Burner
• True Convection Cooking
Control Lock
Yes
Convection
Yes
Delay Bake/Start
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• Temperature Sensor
• Center Oval Burner
• Rapid Preheat (Lower Oven Only)
• Dishwasher-Safe Knobs
• Center Oval Burner
• Rapid Preheat (Lower Oven Only)
• Dishwasher-Safe Knobs
Electrical Information
Information
• 120 V
• 60 Hz
• 60 Hz
Accessories
Included
LP Convertible
Dimensions
Class Width
30"
Width
29.94 inch(es) / 76.04 cm
Height
47.13 inch(es) / 119.7 cm
Depth (Without Handles)
27.25 inch(es) / 69.22 cm
Additional Dimensions
• Depth With Door Open 90 Degree: 46"
• Cutout Depth: 24"
• Cutout Height: 36"
• Cutout Width: 30 1/8"
• Upper Oven Interior Depth: 18-5/8"
• Lower Oven Interior Width: 25"
• Cutout Depth: 24"
• Cutout Height: 36"
• Cutout Width: 30 1/8"
• Upper Oven Interior Depth: 18-5/8"
• Lower Oven Interior Width: 25"
Shipping Dimensions
Width
30.75 inch(es) / 78.11 cm
Height
49.5 inch(es) / 125.73 cm
Depth
30.25 inch(es) / 76.84 cm
Weight
262.99 lb(s) / 119.29 kg
Warranty
Warranty
Limited 1 Year Parts and Labor
UPC
UPC#
883049398976
