Features
WI-FI CONNECT
Control appliances with a smart device or just the sound of your voice.
LED BACKLIT GLASS TOUCH CONTROL
Attractive controls are easy to read and instantly wipe clean.
TRIPLE LED DIMMABLE LIGHTING - BULBS INCLUDED
LED modules ensure bright lighting for the entire cooking environment.
610 CFM
High powered 610 CFM blower adjustable downward to either 380 or 290 maximum CFM to accommodate different installation needs.
Additional Features
4-SPEED FAN CONTROL
Have strong ventilation at four fan speeds that you can adjust to match your cooking techniques.
CONVERTIBLE VENTING OPTIONS
Select recirculating or external venting.
Specifications
General
Series Name
Designer
Blower Included
Yes
Airflow
610 CFM
Style
Chimney
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Wall Mount
Features
Wi-Fi
Yes
Dishwasher-Proof Filters
Yes
Technologies
Wi-Fi Connect
Ducting Information
8" Round Duct
Speeds
4-Speeds:
• 100/1.0 (Working Speed)
• 290/2.5 (Medium Speed)
• 380/4.0 (High Speed)
• 610/- (Boost Speed)
• 100/1.0 (Working Speed)
• 290/2.5 (Medium Speed)
• 380/4.0 (High Speed)
• 610/- (Boost Speed)
Additional Information
• Time Delay Shut-Off
• Removable Filter: Grease and Charcoal
• Exhaust Options: Recirculating Vented to Outside
• LED Cooktop Lighting (3)
• Electronic Touch Controls
• Removable Filter: Grease and Charcoal
• Exhaust Options: Recirculating Vented to Outside
• LED Cooktop Lighting (3)
• Electronic Touch Controls
Electrical Information
Information
120 V
Accessories
Included
Remote Control
Optional
• UX12DC93SS 12' High Ceiling Duct Cover Kit
• UX14DC93SS 14' High Ceiling Duct Cover Kit
• UX14DC93SS 14' High Ceiling Duct Cover Kit
Dimensions
Class Width
30"
Width
29.87 inch(es) / 75.88 cm
Height
27.5 inch(es) / 69.85 cm
Depth
20.12 inch(es) / 51.11 cm
Weight
70 lb(s) / 31.75 kg
Shipping Dimensions
Weight
80.01 lb(s) / 36.29 kg
Warranty
Warranty
Limited 1 Year Parts and Labor
