Features
TRUE CONVECTION COOKING
True convection cooks food faster by using a rear fan and third heating element to circulate hot air over, under, and around food. (Compared to traditional thermal-bake cycle on the same model.)
STORAGE DRAWER
Full width storage drawers offer more storage space.
Additional Features
EZ-2-LIFT™ HINGED CAST-IRON GRATES
Get quick access to spills on the cooktop with our industry-first EZ-2-Lift™ hinged cast-iron grates. The hinged design allows you to wipe up under them without removing them entirely. For a more thorough clean, the grates are also dishwasher-safe.
SCAN-TO-COOK TECHNOLOGY
Get the right settings every time. Scan a frozen food barcode with your smartphone or tablet and send recommended or customized cooking instructions straight to your oven for dinner done the way your family wants it.
FROZEN BAKE™ TECHNOLOGY
Frozen Bake™ technology cooks frozen foods faster by eliminating the need to preheat the oven for your favorite foods such as frozen pizza, lasagna, chicken nuggets, fries and pies.
RAPID PREHEAT
Rapid Preheat uses the bake and broil elements to heat the oven quickly and efficiently.
AQUALIFT® SELF-CLEANING TECHNOLOGY
AquaLift® self-cleaning technology delivers odor-free oven cleaning without chemicals in only 50 minutes.
TEMPERATURE SENSOR
A built-in sensor monitors oven temperature and adjusts the cooking elements to help food bake evenly.
Specifications
General
Fuel Type
Natural Gas
Installation Type
Slide-in
Color
White
Manufacturer Color
White
Appliance Care
AquaLift® Self-Cleaning Technology
Cooktop
Burners/Elements
5
Burners/Elements Output
• Center Rear Burner Power: 10,000 BTU
• Left Front Burner Power: 17,000 BTU
• Left Rear Burner Power: 5,000 BTU
• Right Front Burner Power: 13,000 BTU
• Right Rear Burner Power: 9,500 BTU
• Left Front Burner Power: 17,000 BTU
• Left Rear Burner Power: 5,000 BTU
• Right Front Burner Power: 13,000 BTU
• Right Rear Burner Power: 9,500 BTU
Burners
Sealed
Oven
Capacity (cu. ft.)
5.8 cu. ft.
Number of Ovens
Single
Programs
• Multi-Step Cooking
• Scan-to-Cook
• Voice Control
• Party Mode
• Convect Modes
• Easy Convect Baked Goods
• Easy Convect Meats
• Easy Convect Pizza
• Energy Save Mode
• Favorites
• Frozen Bake
• Full Meal Cook
• Keep Warm Setting
• Language Conversion
• Proofing
• Scan-to-Cook
• Voice Control
• Party Mode
• Convect Modes
• Easy Convect Baked Goods
• Easy Convect Meats
• Easy Convect Pizza
• Energy Save Mode
• Favorites
• Frozen Bake
• Full Meal Cook
• Keep Warm Setting
• Language Conversion
• Proofing
Features
Technologies
• EZ-2-Lift™ Hinged Cast-Iron Grates
• Frozen Bake™ Technology
• Scan-to-Cook Technology
• AquaLift® Self-Cleaning Technology
• SpeedHeat™ Burner
• FlexHeat™ Burner
• Frozen Bake™ Technology
• Scan-to-Cook Technology
• AquaLift® Self-Cleaning Technology
• SpeedHeat™ Burner
• FlexHeat™ Burner
Control Lock
Yes
Convection
Yes
Delay Bake/Start
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Self-Cleaning
Yes
Wi-Fi
Yes
Additional Information
• Touchscreen
• Temperature Sensor
• Rapid Preheat
• Smart Appliance
• Remote Start
• Enhanced Troubleshooting
• Guided Service
• Convection Conversion
• Large Oven Window
• Hidden Bake Element
• Dishwasher-Safe Knobs
• Audible signal
• Bake Element Power: 18,000 BTU
• Broiler Element Power: 11,000 BTU
• Convection Element Power: 900 Watts
• Temperature Sensor
• Rapid Preheat
• Smart Appliance
• Remote Start
• Enhanced Troubleshooting
• Guided Service
• Convection Conversion
• Large Oven Window
• Hidden Bake Element
• Dishwasher-Safe Knobs
• Audible signal
• Bake Element Power: 18,000 BTU
• Broiler Element Power: 11,000 BTU
• Convection Element Power: 900 Watts
Drawer Features
Storage
Yes
Electrical Information
Information
• 120 V
• 60 Hz
• 15 A
• 60 Hz
• 15 A
Certifications and Approvals
ADA Compliant
Yes
Sabbath/Star-K
Yes
Accessories
Optional
Nest Learning Thermostat™
Dimensions
Class Width
30"
Width
29.87 inch(es) / 75.88 cm
Height
36 inch(es) / 91.44 cm
Depth (Without Handles)
27 inch(es) / 68.58 cm
Depth (Including Handles)
28.63 inch(es) / 72.71 cm
Weight
201 lb(s) / 91.17 kg
Additional Dimensions
Depth With Door Open 90 Degrees: 48 7/8"
Shipping Dimensions
Width
31.5 inch(es) / 80.01 cm
Height
43.5 inch(es) / 110.49 cm
Depth
30.5 inch(es) / 77.47 cm
Weight
220.99 lb(s) / 100.24 kg
Warranty
Warranty
Limited 1 Year Parts and Labor
UPC
UPC#
883049426877
