Features
FIT SYSTEM
The FIT system eliminates measuring, cutting and filler strips for a perfect fit every time. The FIT system ensures your hood will install seamlessly into your cabinet cutout in three easy steps.
ECONOMY HOOD SOUND LEVELS
Keep the hood from disturbing family time in the kitchen. This hood features the quiet operation of 4.5 sones at the hood's highest speed with 2 fan speeds and a recirculation option. Based on vertical 7" round duct installation.
HIDDEN VENT
This sleek and stylish hidden vent matches almost every modern or traditional kitchen. The design moves the ventilation out of sight to create a seamless look and a surface that's super easy to clean.
INCANDESCENT LIGHTING
Incandescent bulb provide bright cooktop lighting to make preparation easy.
DISHWASHER SAFE GREASE FILTER
Wash metal filter as needed in dishwasher or hot detergent solution.
Specifications
General
Blower Included
Yes
Airflow
250 CFM
Style
Standard
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Installation
Under-Cabinet
Features
Dishwasher-Proof Filters
Yes
Ducting Information
Rectangular
Speeds
2
Additional Information
• Sones with High Speed: 5.5 (Vertical)
• 40K BTU Threshold
• Convertible to re-circulating
• Rocker switch
• 75 Watt bulb not included
• FIT System installation
• 3-1/4" x 10" Damper
• 40K BTU Threshold
• Convertible to re-circulating
• Rocker switch
• 75 Watt bulb not included
• FIT System installation
• 3-1/4" x 10" Damper
Electrical Information
Information
• 120 V
• 60 Hz
• 60 Hz
Certifications and Approvals
Information
ADA
Dimensions
Class Width
30"
Width
29.94 inch(es) / 76.04 cm
Height
4.94 inch(es) / 12.54 cm
Depth
18.63 inch(es) / 47.31 cm
Weight
14 lb(s) / 6.35 kg
Additional Dimensions
• 24" (61.0 cm) minimum distance from electric cooking surface
• 24" (61.0 cm) minimum distance from gas cooking surface
• 30" (76.2 cm) suggested maximum above the cooking surface
• 18" (45.7 cm) minimum clearance - upper cabinet to countertop
• 12" (30.5 cm) cabinet depth
• 36" (91.4 cm) base cabinet height
• 24" (61.0 cm) minimum distance from gas cooking surface
• 30" (76.2 cm) suggested maximum above the cooking surface
• 18" (45.7 cm) minimum clearance - upper cabinet to countertop
• 12" (30.5 cm) cabinet depth
• 36" (91.4 cm) base cabinet height
Shipping Dimensions
Width
31.75 inch(es) / 80.65 cm
Height
21 inch(es) / 53.34 cm
Depth
7 inch(es) / 17.78 cm
Weight
17 lb(s) / 7.71 kg
Warranty
Warranty
Limited 1 Year Parts and Labor
UPC
UPC#
883049326573
