Features
EVEN-HEAT™ TRUE CONVECTION
Features a unique bow-tie design with heating element and fan that provide even airflow and consistent temperatures throughout the entire oven for crisp, flaky baked goods, juicy, evenly browned roasts and flavorful, caramelized vegetables.
SATINGLIDE™ ROLL-OUT EXTENSION RACK
Makes it easier to cook with large or heavy bakeware. Sure-grip handle and smooth roll-out simplify loading and unloading.
Additional Features
DESIGNED TO BE PERSONALIZED
With a curated palette of exterior finishes and mixed metal hardware. Pick from serene Juniper, warm Black Ore and classic Stainless Steel finishes, all with matching handles and knobs. Personalize your hardware with optional handle and knob accessory kits in Brass, Bronze, Black Ore and Stainless Steel.
NO PREHEAT AIR FRY MODE
Lets you save time and skip preheating while you get crispy and browned food while using less oil than traditional deep frying.
Dishwasher-safe basket sold separately.
Dishwasher-safe basket sold separately.
BACKLIT DUAL-DIAL OVEN KNOB
Gives you the power to control both the oven mode and the temperature. The dual knob lets you select your desired cooking mode of Bake, Broil, or Convection, and then set the temperature. Interactive backlighting confirms your settings or notifies you if adjustments are needed.
.CONVECTION COOKING MODES
Helps you get consistent results with optimal heating temperatures in three different settings. Convect Bake makes carmelized, flavorful vegetables, while Convect Roast gives you juicy roast meats, and Convect Pastry delivers flaky, buttery baked goods.
Specifications
General
Fuel Type
Dual Fuel - Natural Gas
Installation Type
Slide-in
Color
Black
Manufacturer Color
Black Ore
Appliance Care
Self-Cleaning
Cooktop
Burners/Elements
4
Burners/Elements Output
• Left Front Element-Burner Power: 20,000 BTU
• Left Rear Element-Burner Power: 15,000 BTU
• Right Front Element-Burner Power: 20,000 BTU
• Right Rear Element-Burner Power: 5,000 BTU
• Left Rear Element-Burner Power: 15,000 BTU
• Right Front Element-Burner Power: 20,000 BTU
• Right Rear Element-Burner Power: 5,000 BTU
Burners
Sealed
Oven
Capacity (cu. ft.)
4.1 cu. ft.
Number of Ovens
Single
Programs
• Air Fry
• Bake
• Broil
• Clean
• Convect Bake
• Convect Broil
• Convect Roast
• Keep Warm Setting
• Proofing
• Sabbath Mode
• Bake
• Broil
• Clean
• Convect Bake
• Convect Broil
• Convect Roast
• Keep Warm Setting
• Proofing
• Sabbath Mode
Features
Technologies
• True Convection
• Flame-Sensing™ Re-ignition
• Automatic Convection Conversion Temperature Adjust
• Auto Re-Ignition
• Flame-Sensing™ Re-ignition
• Automatic Convection Conversion Temperature Adjust
• Auto Re-Ignition
Air Fry
Yes
Convection
Yes
Digital Temperature Display
No
Oven Light
Yes
Self-Cleaning
Yes
Additional Information
• Hot Surface Indicator Light
• Heating Element On Indicator Light
• Power Outage Compatible - Cooktop Only
• Hidden Bake Element
• 3 Porcelain-Coated Cast Grates
• Gliding Roll-Out and Standard Oven Racks
• 3 Halogen Oven Lights
• True-Bow Tie Convection Element
• Automatic Convection Conversion
• Porcelain-Coated Cast Grates
• Dishwasher-Safe Grates
• Matte Finish Grates
• Natural Gas Convertible
• LP Convertible
• Heating Element On Indicator Light
• Power Outage Compatible - Cooktop Only
• Hidden Bake Element
• 3 Porcelain-Coated Cast Grates
• Gliding Roll-Out and Standard Oven Racks
• 3 Halogen Oven Lights
• True-Bow Tie Convection Element
• Automatic Convection Conversion
• Porcelain-Coated Cast Grates
• Dishwasher-Safe Grates
• Matte Finish Grates
• Natural Gas Convertible
• LP Convertible
Electrical Information
Information
Amps - 50.0 A
Certifications and Approvals
Sabbath/Star-K
Yes
Information
• CUL
• UL
• UL
Accessories
Optional
• W11774724
• W11774725
• W11774726
• Power Cord
• W11774725
• W11774726
• Power Cord
Dimensions
Class Width
30"
Width
29.88 inch(es) / 75.9 cm
Height
36 inch(es) / 91.44 cm
Depth (Without Handles)
27.75 inch(es) / 70.49 cm
Depth (Including Handles)
30.25 inch(es) / 76.84 cm
Weight
298.99 lb(s) / 135.62 kg
Additional Dimensions
• Overall Depth - 28.5 "
• Depth With Door Open 90 Degree - 46.5 "
• Cutout Depth - 24.0 "
• Cutout Height - 36.0 "
• Cutout Width - 30.0 "
• Oven Interior Width - 24.0 "
• Oven Interior Depth - 16.3 "
• Depth With Door Open 90 Degree - 46.5 "
• Cutout Depth - 24.0 "
• Cutout Height - 36.0 "
• Cutout Width - 30.0 "
• Oven Interior Width - 24.0 "
• Oven Interior Depth - 16.3 "
Shipping Dimensions
Width
35.8 inch(es) / 90.93 cm
Height
47.3 inch(es) / 120.14 cm
Depth
35.5 inch(es) / 90.17 cm
Weight
362.4 lb(s) / 164.38 kg
Warranty
Warranty
1-Year parts and labor
UPC
UPC#
883049919171
